During construction, the foundation of your ideal home should be prioritized above all other factors. This is because a good foundation keeps a structure robust and upright. In addition, a solid foundation keeps moisture out and the house well-insulated. However, if the foundation is unstable, it might endanger your family living inside in the future. As a result, and depending on your construction requirements, you can select from various foundation types while building a house or another structure. Based on the site, climate, local humidity, soil conditions, and last but not least, the budget, builders select from several types of foundations for your house. The following 7 foundation types are most common in the U.S., and we provide a summary of each to help you further understand what lies beneath your home:

Basement Foundation

This foundation begins with an 8-feet deep hole in the ground to accommodate an underground living area. Additionally, the contractor must place structural foundation walls on top of the concrete footings surrounding the basement. Basement foundation concrete footings must be positioned at least 12 inches below unaltered soil and a foot below the frost line. The construction team then builds foundation walls, pours beams, and fills the walls with cement. Basement foundations can be pricey unless you are building a daylight basement. This style of basement enables light to penetrate at least from one side. No matter the type of basement, waterproofing experts like those at BARRIER Waterproofing Systems advise a sump pump installation in the basement, even in hilly locations. This is because of the tendency for moisture to intrude on foundation walls driven by forces like hydrostatic pressure, etc.

Crawlspace Stem Walls

The sort of foundation described by the name "crawlspace stem wall foundation" is formed exactly how it sounds like it is. The stem wall installation allows for a little higher "crawling space" under the home. This area frequently serves as a furnace or room for other equipment and item storage. These foundations are primarily used in construction to shield the house from environmental dangers like floods. Additionally, the provided room makes it simpler to access mechanical systems like wiring and piping for making home repairs. These building foundations are popular among architects who create homes in earthquake-prone regions because they are ideal for warmer temperatures like the Northwest and Southern regions.

Concrete Slab Foundations

Because only one concrete slab is laid on the ground, this foundation is sometimes referred to as a monolithic slab foundation. The fact that these foundations are inexpensive and quick to build is their greatest strength. Its installation requires a rather simple procedure. On each side of the slab's perimeter, a beam is sunk two feet deep into the concrete, and the concrete is reinforced with steel bars and wire mesh. The homeowner of this foundation does not have to bother about upkeep because their foundation lacks a crawl area.

Wood Foundations

A wood foundation might seem unusual now, but it was widespread in the 1960s. Nowadays, construction workers utilize inexpensive, decay-resistant timber that has been preservative-treated. These foundations are more affordable and easier to install because they don't require labor-intensive work or concrete pouring. To increase the ability to provide a warm crawlspace, the foundation can be insulated. In an ideal environment, wooden foundations remain sturdy. In the pyramids of ancient Egypt, for example, archaeologists have discovered cypress wood beams that are 6,000 years old! Some types of wood, like cedar, cypress, and redwood, are inherently resistant to insects and mildew, although they are costly. As a result, the industry has discovered innovative methods to treat different woods and give them comparable properties.

Pier and Beam Foundations

Since the soil in coastal locations is continuously moving, flooding, and eroding, pier and beam foundations are perfect. The "pile and pier" or "post and pier" foundation is another name for the pier and beam foundation. Due to the necessity to shield the home from moisture, these foundations are typically seen in hurricane-prone or heavily flooded locations. Providing superior support in situations where the weight of the building may be distributed across a huge area, these foundations are frequently built for massive houses. However, a soil study must be done by a supervising structural engineer who maintains the proper conditions to keep the home from sinking.

End-Bearing Piles

Even with shallow foundations and dirt compactors, the earth sometimes just can't support the weight of the structure being erected. To equally distribute the weight, builders avoid the soft layer of earth and instead access the bedrock beneath it. For the piles to reach the rocky layer underneath the soil, they must be driven as deeply into the ground as they can. This enables a safe weight displacement by distributing the weight through to the load-bearing strata formations below.

Mat Foundation

A shallow form of a foundation called a mat foundation uses the basement as the primary load-bearing source while still utilizing the entire surface area of the site. These kinds of construction foundations are perfect in situations where the soil needs to be displaced equally since it is fragile and loose. This foundation is also excellent for when there is a possibility of future basement installation, and the columns are placed evenly and close to one another. Given that the basement foundation is buried in the ground like the underwater hull of a raft, it is sometimes referred to as a "raft foundation." The choice of whether to construct a deep or shallow foundation may seem obvious. The precise type of foundation to pick may merit a more complex decision depending on the size, location, and geotechnical problems your building project must overcome. Making the appropriate choice is crucial since a building's foundation is vital to its overall structural stability.

Foundation Repair & Replacement Solutions

For more information regarding the type of foundation under your home, as well as its current condition, give PIERMAN Foundation Repair a call today at (580) 453-0330. Our foundation repair experts will evaluate your home and determine the best solution for you. Repairing or replacing your foundation is our specialty, and we can help restore the integrity of your home in no time. Visit our website to learn more and to schedule an evaluation to take the first step toward achieving a more stable home.
